Totolink SW804P 8 Port POE 10/100 Switch

Manufacturing Warranty

1 Year Warranty

Dimensions (L x W x H )

158.4mm x 106.5mm x 27mm

Interface

4*10/100Mbps PoE Ports 4*10/100Mbps auto-negotiation RJ-45 Ports

Power Supply

AC：100-240V～ 50/60Hz DC : 48V /1.25A（Power Adapter )

LED	1*Power 4*PoE 1*Overload 8* Link/Act

Port	4*10/100Mbps PoE Ports, 4*10/100Mbps auto-negotiation RJ-45 Ports

Network Standard

IEEE 802.3af, IEEE 802.3 IEEE 802.3u IEEE 802.3x

Data Transmission Rate

10/100Mbps

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing

MAC Address Table

1k

Transmission Method

Store-and-forward

Advanced Functions

Port Lightning Protection: 6KV

Totolink SW804P 8 Port POE 10/100 Switch

The SW804P is a 8-port 10/100Mbps Ethernet Switch with 4 ports support Power over Ethernet(PoE). All these four ports can detect connected devices automatically and deliver power & data to all IEEE 802.3af compliant PoE powered devices through one Ethernet cable. SW804P supports plug-and-play and can also be simply connected to a server, a hub or a switch using straight cable or crossover cable.
